SVC-2 Voltammetry cell

4 WAYS APPLICATION
SVC-2 Voltammetry cell can be used as a previous VC-2, VC-5, MCA and SVC-3C. Each Voltammetry cell has its specific feature. However, SVC-2, you can be used in four way, and also you can apply as a oxygen-free voltammetry cell.

SVC-2 Voltammetry cell


Features:
⇒ For various types of electrodes
⇒ Sample volume from 5 to 20 mL
⇒ Easy removal of the dissolved oxygen


























Working electrode and reference electrode are sold separately. Each component could be purchased separately. For acquisition separately, the sample vial of 20 mL is composed for 20 pieces.


Catalog No. Description Teflon cap for SVC-3
012668 SVC-3 Voltammetry cell
Contents
(001056) Sample vial (20 ml) 7 pcs
002222 Pt counter electrode
012670 Teflon cap for SVC-2
(010537) Purging tube
Optional item
012177 Sample holder dia 9 mm (2pcs)



SVC-2 Voltammetry cell feature

Four ways applications:

VC-2 Voltammetry cell mode Set the Teflon cap adaptor to the Teflon cap.
The Teflon cap adaptor is fixed with a silicon O-ring to work in an oxygen-free condiction.
If you do not need the oxygen-free condiction, then the silicon O-ring can be taken out from the Teflon cap.

VC-2 mode fits:
- Working electrode (until OD: 6.0 mm)
- Reference electrode
- Pt Counter electrode for VC-2
- Purging tube
Take out the Teflon cap adaptor from the Teflon cap.
Working electrode can be fitted directly to the Teflon cap.
The O-ring will fit perfectly. It permits to have the oxygen-free condition.

VC-5 mode fits:
- Working electrode (OD: 10.0 mm)
- Reference electrode
- Pt Counter electrode for VC-2
- Purging tube
VC-5 Voltammetry cell mode
MCA Voltammetry cell mode Take out the Teflon cap adaptor from the Teflon cap, and set the Sample holder of the 9.0 mm of the diameter (optional item).
Set the working electrode and counter electrode into the Sample holder.

MCA mode fits:
- Sample holder (φ 9.0 mm)
  →Working electrode
  →Counter electrode
- Reference electrode
- Purging tube

Do not work in a oxygen-free condition.
Take out the Teflon cap adaptor, and set the Sample holder of the 9.0 mm diameter (optional item).
Set the reference electrode into the sample holder.

SVC-3C mode fits:
- Sample holder (φ 9.0 mm)
  →Reference electrode
- Pt Counter electrode for VC-2
- Micro electrode
- Purging tube
SVC-3 Voltammetry cell mode



Voltammetry cell - Lineup

Cell Vial Lineup
SVC-3 Voltammetry cell
VC-4 Voltammetry cell

Available until March 2011  (Please confirm availability)
VC-2 Voltammetry cell
VC-3 Voltammetry cell
VC-5 Voltammetry cell
MCA Micro cell
SVC-3C Voltammetry cell
